Photometric / IES Files
The following list of IES Photometric files are plain text files that contain data on light for architectural programs that can simulate light. These are available for use by designers and architects, to determine how their designs interact with our Electric Mirror products, so they can better understand the lighting patterns.
IES files contain detailed photometric data on measuring light levels. Knowing the total output of your new lighted mirror is important as you develop a lighting system.
We are adding these files as they are available. If you do not see a specific product listed below, send an email to [email protected] to inquire about availability. Please note that not all products have photometric data.
Lighted Mirrors
Eternity
30″ diameter x 1.75″D (762mm x 44mm)
42″ diameter x 1.75″D (1066mm x 44mm)*
Fusion
36″W x 36″H x 1.75″D (914mm x 914mm x 44mm)
48″W x 36″H x 1.75″D (1219mm x 914mm x 44mm)
60″W x 36″H x 1.75″D (1524mm x 914mm x 44mm)
Integrity
36″W x 36″H x 1.75″D (914mm x 914mm x 44mm)
60″W x 36″H x 1.75″D (1524mm x 914mm x 44mm)
Novo
36″W x 36″H x 1.75″D (914mm x 914mm x 44mm)
60″W x 36″H x 1.75″D (1524mm x 914mm x 44mm)
Silhouette
36″W x 36″H x 1.75″D (914mm x 914mm x 44mm)
60″W x 36″H x 1.75″D (1524mm x 914mm x 44mm)
Trinity
30″ diameter x 1.75″D (762mm x 44mm)
42″ diameter x 1.75″D (1066mm x 44mm)*
Corridor Lighting
Madison
5″W x 30″H x 1.69″D (127mm x 762mm x 43mm)
5″W x 42″H x 1.69″D (127mm x 762mm x 43mm)
5″W x 60″H x 1.69″D (127mm x 762mm x 43mm)
*Not a standard size. Minimum order quantity required.
